Cable Tray Fittings And Accessories

Embrace the reliability of our Cable Tray Fittings and Accessories, expertly manufactured and supplied by us, a trusted name with over 23 years of experience as a leading manufacturer, supplier, and exporter. Our top-rated product range, including Tee Bend (Ladder Type), Horizontal Bend Cornered (Perforated Type), Ladder Type Reducer Bend Left, Lockable Clamp, and Cross Bend (Ladder Type), is designed for seamless integration and superior performance in cable management systems across All India. Built to the highest industry standards, these fittings and accessories feature unparalleled load-bearing strength, ensuring the safe and secure routing of cables even in demanding industrial environments. Their new innovative designs offer unrivaled flexibility and effortless installation, catering to diverse configuration needs. Our cable tray fittings have marvelous corrosion resistance, making them the top choice for both indoor and outdoor applications. Enhanced with excellent durability and precision, they deliver long-lasting service and superior reliability. Compared to conventional options, our products stand out for their advanced locking mechanisms and ease of use, making cable management more efficient and robust. Choose our Cable Tray Fittings and Accessories for your next project and experience the ultimate in performance, safety, and dependability.
Cross Bend (Ladder Type)

Cross Bend (Ladder Type)

MOQ : 10 Pieces

  • Color
  • Other, Metallic grey, silver, or as per customer request
  • Conductor Material
  • Other, Steel or Aluminum
  • Deflection
  • Less than 1/200th of the span under max. load
  • Dimension (L*W*H)
  • As specified/drawn by project
  • Length
  • Customized as per requirement
  • Material
  • Other, Mild Steel (MS), Pre Galvanized Steel, Hot Dip Galvanized Steel, Stainless Steel, Aluminum
  • Max. Working Load
  • Up to 150 kg/m (depending on tray size and support spacing)
  • Product Type
  • Other , Ladder Type Cable Tray Cross Bend
  • Side Rail Height
  • 50 mm, 75 mm, 100 mm, 150 mm (custom sizes available)
  • Standard Thickness
  • 1.2 mm to 3.0 mm
  • Surface Finish
  • Other, Hot Dip Galvanized, Pre-Galvanized, Powder Coated, Painted, or SS finish
  • Weight
  • Varies depending on size and material (typically 5 kg - 20 kg per piece)
  • Width
  • 100 mm to 1200 mm (Standard options available: 150 mm, 300 mm, 450 mm, 600 mm, 900 mm)
Know more
Cross Bend (Perforated Type)

Cross Bend (Perforated Type)

MOQ : 10 Pieces

  • Color
  • Other, Silver / Natural Metal Finish or as required
  • Conductor Material
  • Other, Not applicable (for cable support only)
  • Deflection
  • Within IS/IEC standard limits
  • Dimension (L*W*H)
  • Customizable as per requirements
  • Length
  • Variable as per application (typically 300 mm to 1000 mm)
  • Material
  • Other, Mild Steel (MS) / Pre-Galvanized (GI) / Stainless Steel
  • Max. Working Load
  • Varies based on material, width, and thickness (typically 30 kg - 100 kg)
  • Product Type
  • Other , Cross Bend (Perforated Type)
  • Side Rail Height
  • 25 mm, 50 mm, 75 mm, 100 mm
  • Standard Thickness
  • 1.2 mm, 1.5 mm, 2.0 mm, and 2.5 mm
  • Surface Finish
  • Other, Pre-Galvanized, Hot-Dip Galvanized, Powder Coated, or Painted
  • Weight
  • Depends on size and material; typically 1.5 kg to 8 kg
  • Width
  • 50 mm to 1000 mm
Know more
Horizontal Bend (Ladder Type)

Horizontal Bend (Ladder Type)

MOQ : 10 Pieces

  • Color
  • Other, Metallic Grey, customizable on request
  • Deflection
  • Minimal, within standard allowable limits
  • Dimension (L*W*H)
  • Custom as per requirement
  • Length
  • Up to 2500 mm
  • Material
  • Other, Mild Steel (MS), Stainless Steel (SS), Aluminum (AL)
  • Max. Working Load
  • Up to 150 kg/m or as specified
  • Product Type
  • Other , Horizontal Bend (Ladder Type)
  • Side Rail Height
  • 50 mm to 150 mm
  • Standard Thickness
  • 1.2 mm to 3 mm
  • Surface Finish
  • Other, Hot-Dip Galvanized / Pre-Galvanized / Epoxy Coated / Powder Coated
  • Weight
  • Varies as per dimension and material
  • Width
  • 100 mm to 1200 mm
Know more
Horizontal Bend Cornered (Perforated Type)

Horizontal Bend Cornered (Perforated Type)

MOQ : 10 Pieces

  • Color
  • Other, Silver (standard), other finishes on request
  • Conductor Material
  • Other, Not applicable (used for cable routing/support only)
  • Deflection
  • Within industry standard limits for cable trays
  • Dimension (L*W*H)
  • As per drawing or customer requirement
  • Length
  • Customizable as per project requirement
  • Material
  • Other, Mild Steel (MS) / Pre-Galvanized Steel / Stainless Steel / Aluminum
  • Max. Working Load
  • Depends on width, thickness, and installation method
  • Product Type
  • Other , Horizontal Bend (Cornered, Perforated Type)
  • Side Rail Height
  • 25mm to 150mm
  • Standard Thickness
  • 1.2mm / 1.5mm / 2.0mm / 2.5mm / 3.0mm
  • Surface Finish
  • Other, Hot Dip Galvanized / Pre-Galvanized / Powder Coated / Painted
  • Weight
  • Varies according to size and material
  • Width
  • 50mm to 1000mm
Know more
Lockable Clamp

Lockable Clamp

MOQ : 10 Pieces

  • Color
  • Other, Silver / Metallic
  • Conductor Material
  • Other, Not Applicable / Optional Copper Inserts
  • Deflection
  • Minimal, <1 mm under rated load
  • Dimension (L*W*H)
  • Depends on selected configuration; e.g., 150 mm x 40 mm x 60 mm
  • Length
  • Customizable or 100 mm - 300 mm (typical range)
  • Material
  • Other, Stainless Steel / Galvanized Steel / Mild Steel
  • Max. Working Load
  • Up to 300 kg
  • Product Type
  • Other , Lockable Clamp
  • Side Rail Height
  • 40 mm - 60 mm
  • Standard Thickness
  • 2 mm - 5 mm
  • Surface Finish
  • Other, Zinc Plated / Mirror Finish / Satin Finish
  • Weight
  • 350 g - 1.5 kg (depending on size)
  • Width
  • 40 mm - 60 mm (varies by model)
Know more
Ladder Type Reducer Bend Left

Ladder Type Reducer Bend Left

MOQ : 10 Pieces

  • Color
  • Other, Metallic Grey / Silver / Powder Coated Finish
  • Conductor Material
  • Other, Not Applicable (for supporting cable routing only)
  • Deflection
  • 3 mm (under max. load, as per standards)
  • Dimension (L*W*H)
  • 1000 mm x 300 mm x 100 mm
  • Length
  • 1000 mm
  • Material
  • Other, Mild Steel / Stainless Steel / Aluminum
  • Max. Working Load
  • 100 kg/m (Based on width and thickness)
  • Product Type
  • Other , Ladder Type Reducer Bend Left
  • Side Rail Height
  • 75 mm / 100 mm
  • Standard Thickness
  • 1.5 mm / 2.0 mm / 2.5 mm (customizable)
  • Surface Finish
  • Other, Pre-Galvanized / Hot Dip Galvanized / Powder Coated
  • Weight
  • 8.2 kg (approx., varies with size)
  • Width
  • 300 mm
Know more
Tee Bend (Ladder Type)

Tee Bend (Ladder Type)

MOQ : 10 Pieces

  • Color
  • Other, Natural metallic finish or powder coated (grey, silver, or other customized)
  • Conductor Material
  • Other, Not applicable (for cable tray body: refer material)
  • Deflection
  • Maximum allowable deflection 1/200th of span
  • Dimension (L*W*H)
  • As per specified cable tray size, e.g. 2500x300x100 mm
  • Length
  • Customizable (typically 1000 mm, 2500 mm, or as per project design)
  • Material
  • Other, Mild Steel, GI (Galvanized Iron), Stainless Steel, Aluminum
  • Max. Working Load
  • Up to 150 kg/m (depends on width and support span)
  • Product Type
  • Other , Tee Bend Ladder Type Cable Tray
  • Side Rail Height
  • 50 mm to 150 mm
  • Standard Thickness
  • 1.6 mm to 3 mm
  • Surface Finish
  • Other, Hot Dip Galvanized, Pre-Galvanized, Painted, or Powder Coated
  • Weight
  • Depends on dimensions and material (Approx. 6-25 kg/unit)
  • Width
  • 100 mm to 1200 mm (standard options)
Know more
Perforated Type Tee Bend

Perforated Type Tee Bend

MOQ : 10 Pieces

  • Color
  • Other, Silver/Grey (Metallic)
  • Conductor Material
  • Other, Steel / Aluminum
  • Deflection
  • Within permissible limits according to IS/IEC standards
  • Dimension (L*W*H)
  • Customized as per cable tray size
  • Length
  • Standard and customized as per requirement
  • Material
  • Other, Mild Steel / Pre-Galvanized / Hot Dip Galvanized / Stainless Steel / Aluminum
  • Max. Working Load
  • Depends on tray size and material grade
  • Product Type
  • Other , Perforated Type Tee Bend
  • Side Rail Height
  • 25 mm to 150 mm
  • Standard Thickness
  • 1.2 mm to 3.0 mm
  • Surface Finish
  • Other, Galvanized / Powder Coated / Hot Dip Galvanized
  • Weight
  • Varies as per dimensions and material
  • Width
  • 50 mm to 1000 mm
Know more
Vertical Bend - Inward (Perforated Type)

Vertical Bend - Inward (Perforated Type)

MOQ : 10 Pieces

  • Color
  • Other, Natural Metal / Silver
  • Conductor Material
  • Other, Steel or as per requirements
  • Deflection
  • Less than 2.5 mm at max load
  • Dimension (L*W*H)
  • Depends on model; e.g., 300 mm radius x 100 mm width x 75 mm height
  • Length
  • Customized as per cable tray size or up to 300 mm standard
  • Material
  • Other, Mild Steel, Pre-Galvanized Steel, Stainless Steel, Aluminum
  • Max. Working Load
  • Depends on width and gauge, typically up to 250 kg
  • Product Type
  • Other , Vertical Bend - Inward (Perforated Type)
  • Side Rail Height
  • 40 mm to 150 mm
  • Standard Thickness
  • 1.2 mm, 1.6 mm, 2.0 mm, 2.5 mm
  • Surface Finish
  • Other, Hot Dip Galvanized / Pre-Galvanized / Powder Coated
  • Weight
  • Varies with size and thickness, approx. 2 kg to 12 kg/pc
  • Width
  • 50 mm to 1000 mm (custom available)
Know more
Vertical Bend - Outward (Ladder Type)

Vertical Bend - Outward (Ladder Type)

MOQ : 10 Pieces

  • Color
  • Other, Metallic Grey / Silver
  • Conductor Material
  • Other, Not Applicable (For Cable Management)
  • Deflection
  • Within allowable engineering limits (as per IS standards)
  • Dimension (L*W*H)
  • Customized; typical: 1000 mm x 300 mm x 100 mm
  • Length
  • Customizable as per cable tray requirements
  • Material
  • Other, Mild Steel (MS) / Pre-Galvanized Steel / Stainless Steel
  • Max. Working Load
  • 50 kg/m to 150 kg/m
  • Product Type
  • Other , Vertical Bend (Outward) Ladder Type Cable Tray
  • Side Rail Height
  • 50 mm to 150 mm
  • Standard Thickness
  • 1.6 mm, 2.0 mm, 2.5 mm, 3.0 mm
  • Surface Finish
  • Other, Hot Dip Galvanized / Pre-Galvanized / Powder Coated
  • Weight
  • Varies as per Dimension and Material (example: 5 kg - 25 kg)
  • Width
  • 100 mm to 1200 mm (customizable)
Know more
